Description
Windlasses on-deck PTR 250W/12V - 700Lb with bow-roller in AISI 316 stainless steel and anodised aluminium. IP67 watertight motor. Suitable for boats 8-12mt (26-39ft).
The PTR can be equipped with bow-roller to make it more functional and practical for its use on boats not equipped for installation of anchor such as some types of multihull.
The bow-roller Quick is designed specifically to sail anchor in safety, thanks to the system that locks the anchor at the end of recovery.
The kit includes PTR, AISI 316 stainless steel bow-roller and high tenacity rope (Dyneema).
Features Windlasses on-deck PTR:
- Motor power: 250W;
- Motor supply voltage: 12V;
- Maximum pull: 600Kg;
- Maximum working load: 220Kg;
- Working load: 80Kg;
- Current absorbtion working load: 22A;
- Maximum chain speed: 20,8 m/min;
- Maximum chain speed working load: 18.1 m/min;
- High tenacity Dyneema including rope length: 30mt (max rope length 30mt);
- Rope diameter: 6mm;
- Weight: 10,2kg.
The box contains only the contactor; switches and push buttons are sold separately.
A circuit breaker is recommended.
