Suitable for all applications where 230 Vac loads are required from a low 12 Vdc voltage power source. This inverter has an harmonic distortion of less than 3% and can therefore power the most modern and sophisticated utilities.
It has a no load consumption of less than 0.53A, and in the event of the batteries reaching a voltage of about 10.6V it enters into protection mode to then switch off at 10.4V, thereby protecting the batteries from deep discharge.
Technical data:
- DC 12V to AC 230V;
- 1200W continuous power inverter;
- 2400W Surge power;
- No Load Curent Draw: < 0.53A;
- Pure sine wave output;
- Range Input Voltage: 10.8V-15.5V;
- Output voltage: 230V;
- Frequency: 50Hz;
- Low battery alarm: 10.6V± 0.4V;
- Low battery shut down: 10.4±0.4V;
- Soft Start;
- Dimensions: 320x160x77 cm;
- Weight: 2.65 kg.
WARNING
IF YOU INTEND TO USE INDUCTIVE LOADS IT IS NECESSARY TO CHOOSE AN INVERTER 5 TIMES MORE POWERFUL THAN THE APPLIED LOAD. FOR EXAMPLE, IF YOU WANT TO USE AN INDUCTIVE LOAD OF 1000W THEN A 5000W INVERTER IS NECESSARY.
